AUXT5500全自動吹瓶機

鑫泰吹瓶機|ASNTO|AUXT5500吹瓶機系列

詳情

AUXT5500全自動吹瓶機|鑫泰吹瓶機|ASNTO|SNTO

特點|TECHNICAL FEATURES

??密集型加熱節能型設計 ? ?Intensive Heating Systemr Power Saving Ecnomical Machine

??占地面積小 ? Space Saving Smart Machine?

??可選擇伺服開合模、步進及拉伸系統 ? ? Optional Servo Motor For Mold Claming,pre-form Forwarding And Preform Stretching System,Efficient Maching

??每腔瓶坯加熱及吹瓶延時調整都可獨立控制 ? ? ?Preform Heating And Blowing Delay Individu-ally Controlled

Model No.型號? AUXT5500	1	2	3	4
number of cavity 模穴數	1	2	3	4
clamping stroke 開模行程	200 mm	200 mm	200 mm	200 mm
production 理論產量	600pcs/hr	900pcs/hr	1600pcs/hr	2800pcs/hr
total power 總裝機容量	36 kw	45kw	65 kw	80 kw
actual power consumption 實際耗電量	≤15 kw	≤20 kw	≤28 kw	≤38 kw
pressure for working 動作用氣壓力	10 kg	10 kg	10 kg	10 kg
pressure for blowing 允許吹氣壓力	30 kg	30 kg	30 kg	30 kg
flow rate for working 動作用氣量	2.5 m3	2.5 m3	1.5 m3	1.5 m3
flow rate for blowing 吹氣用氣量	4.0 m3	3.5 m3	3.5 m3	3.5 m3
neck diameter 允許瓶口直徑	24-45 mm	24-45 mm	24-40 mm	24-40 mm
max diameter 允許瓶身直徑	180 mm	180 mm	180 mm	180 mm
max height 允許瓶身高度	330 mm	320 mm	320 mm	320 mm
machine size LxWxH 機器尺寸	2.5x1.8x2.2 m	2.5x2.2x2.2 m	3.5x2.2x2.2 m	5.0x2.2x2.2 m
auto loaderR LxWxH 上料機構	1.7x2.7x2.7	1.7x2.7x2.7	1.7x2.7x2.7	1.7x2.7x2.7
machine weight 機器重量	2000 kg	2500 kg	4500 kg	7500 kg
